CFORCE 520 S AGRI

The CFORCE 520 S/L is equipped with the latest evolution of the CFMOTO medium displacement engine. With a cubic capacity of 495 cm3, this 34 HP engine with a single overhead camshaft is at the cutting edge of technology: liquid-cooled and powered by a Bosch 40 mm throttle body. With ESP as standard and the choice of a single or double seat, the 520 S/L is a concentrate of CFMOTO DNA.

CFORCE 520 S AGRI

The CFORCE 520 S/L is equipped with the latest evolution of the CFMOTO medium displacement engine. With a cubic capacity of 495 cm3, this 34 HP engine with a single overhead camshaft is at the cutting edge of technology: liquid-cooled and powered by a Bosch 40 mm throttle body. With ESP as standard and the choice of a single or double seat, the 520 S/L is a concentrate of CFMOTO DNA.

Engine Type	Monocylinder, 4-valve, SOHC, EFI, Liquid cooled
Displacement	495 cm3
Maximum Power	28 kW / 6800 rpm / 37.5 hp*
Maximum Speed	60 km/h
Fuel Supply	EFI
Ignition	ECU
Transmission	CVT
Drive	Switchable 2WD/4WD

*Maximum power is depending on the regulation of the vehicle.

Brake	Hydraulique
Suspension	Double triangle
Shock Absorber	Oil / Gas shock absorber
Front Rim	12 x 6.0 AT Aluminium Alloy / Steel
Rear Rim	12 x 7.5 AT Aluminium Alloy / Steel

Dimensions (L x W x H)	2090 x 1100 x 1150 mm
Wheelbase	1260 mm
Seat Height	540 mm
Minimum Ground Clearance	250 mm
Curb Weight	345 kg
Payload Capacity	150 kg
Fuel Capacity	15 L

Royal Blue

Non-contractual pictures, may differ from reality.

CFORCE 520 S AGRI

CFORCE 520 S AGRI

*Maximum power is depending on the regulation of the vehicle.

LED Lights

NITROGEN GAS CHARGED SHOCKS

GROUND CLEARANCE
